Hilti TE 3-C User Manual

6 English 2058841
*2058841*
TE 3M TE 3C
Storage temperature
−4 ℉ … 158 ℉
(−20 ℃ … 70 ℃)
−4 ℉ … 158 ℉
(−20 ℃ … 70 ℃)
Ambient temperature
for operation
1 ℉ … 140 ℉
(−17 ℃ … 60 ℃)
1 ℉ … 140 ℉
(−17 ℃ … 60 ℃)
5 Operation
TE 3-M
Changing the quick-release chuck
3
Fitting the side handle
CAUTION
Risk of injury! The depth gauge, if fitted but not used, might hinder the operator.
▶ Remove the depth gauge from the tool.
CAUTION
Risk of injury! Loss of control over the rotary hammer drill.
▶ Check that the side handle is fitted correctly and tightened securely. Check that the clamping
band is engaged in the groove in the tool.
4
Fitting/removing the drill bit or other accessory: SDS quick-release chuck
Use of unsuitable grease may cause damage to the product. Use only the
recommended grease supplied by Hilti.
5
TE 3-M
Fitting/removing the drill bit, chisel or other accessory: Three-jaw chuck
6
Drilling without hammering
7
Screwdriving
7
Drilling with hammering action (hammer drilling)
7
Setting the chiseling function
7
Chisel positioning
CAUTION
Risk of injury Loss of control over the chisel direction.
▶ Do not operate the tool when the selector switch is set to “Chisel positioning”. Turn the
function selector switch until it engages in the “Chiseling” position.
7
Forward / reverse
8
Adjusting the depth gauge
9
Fitting the dust collection module for overhead work
10
Pressing/locking the control switch
11
Replacing the dust shield
12
6 Care of the product
▶ Keep the product, especially its grip surfaces, clean and free from oil and grease. Do not use
cleaning agents containing silicone.
▶ Never operate the product when the air vents are blocked. Clean the air vents carefully using a dry brush.
Do not allow foreign objects to enter the interior of the product.
▶ Clean the outside of the product at regular intervals with a slightly damp cloth. Do not use a spray, steam
pressure cleaning equipment or running water for cleaning.
Printed: 20.12.2018 | Doc-Nr: PUB / 5245520 / 000 / 04

Hilti TE 3-C Specifications

General

Drilling	Yes
Chuck type	SDS Plus
Product color	Black, Red
Country of origin	Germany
Input power	850 W
Power source	AC
Power plug type	Type C
Impact rate	5160 bpm
Rated speed (max)	1300 RPM
Impact energy (max)	2.5 J
Vibration level (hammer drilling)	15.5 m/s²
Drilling diameter in concrete (max)	28 mm
Optimum drilling diameter (concrete)	6 - 16 mm
Noise level	92 dB
Number of shipping (inner) cases per master (outer) case	1 pc(s)

Weight and Dimensions

Weight	3000 g
Package depth	3456 mm
Package width	2000 mm
Package height	4500 mm
Package weight	4500 g
