3 Description
3.1 Product overview 1
@
Tool holder
;
Depth gauge
=
Function selector switch
%
Control switch
&
Service indicator
(
Supply cord
)
Side handle
3.2 Version with detachable supply cord 2
@
Lockbutton
;
Connector on electric tool
=
Supply cord with keyed, releasable plug
connector
3.3 Intended use
The product described is an electrically-powered combihammer with pneumatic hammering mechanism. It
is designed for drilling in concrete, masonry, wood and metal. The product can also be used for light to
medium-duty chiseling on masonry and surface finishing work on concrete.
▶ Operation is permissible only when connected to a power source providing a voltage and frequency in
compliance with the information given on the type identification plate.
3.4 Possible misuse
• This product is not suitable for working on hazardous materials.
• This product is not suitable for working in a damp environment.
3.5 Active Vibration Reduction
The tool is equipped with an Active Vibration Reduction (AVR) system which reduces vibration noticeably.
3.6 Quick-release chuck (accessory)
The quick-release chuck makes changing accessory tools a quick operation with no additional tools needed.
It is suitable for accessory tools with cylindrical or hexagonal shank used in the "Without hammering action
" mode.
3.7 Service indicator
The product has an LED service indicator.
Status Meaning
Service indicator shows Servicing is due.
Service indicator flashes The product is faulty. Have the combihammer re-
paired by Hilti Service.
