1.3 Product-dependent symbols
1.3.1 Symbols on the product
The following symbols are used on the product:
Drilling with hammer action (hammer drilling)
Chiseling
Chisel positioning
Protection class II (double-insulated)
Revolutions per minute
Rated speed under no load
Diameter
Wireless data transfer
1.4 Product information
products are designed for professional users and only trained, authorized personnel are
permitted to operate, service and maintain the products. This personnel must be specifically informed about
the possible hazards. The product and its ancillary equipment can present hazards if used incorrectly by
untrained personnel or if used not in accordance with the intended use.
The type designation and serial number are printed on the rating plate.
▶ Write down the serial number in the table below. You will be required to state the product details when
contacting Hilti Service or your local Hilti organization to inquire about the product.
Product information
Combihammer TE 50AVR
Generation 03
Serial no.
1.5 Declaration of conformity
We declare, on our sole responsibility, that the product described here complies with the applicable directives
and standards. A copy of the declaration of conformity can be found at the end of this documentation.
The technical documentation is filed here:
Hilti Entwicklungsgesellschaft mbH | Tool Certification | Hiltistrasse 6 | 86916 Kaufering, Germany
2 Safety
2.1 General power tool safety warnings
WARNING Read all safety warnings, instructions, illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated
(cordless) power tool.
Work area safety
▶ Keep work area clean and well lit. Cluttered or dark areas invite accidents.
▶ Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
▶ Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.

Hilti TE 50-AVR Specifications

General

Drilling	Yes
Chuck type	SDS Max
Product color	Black, Red
Country of origin	Germany
Impact rate	3180 bpm
Rated speed (max)	360 RPM
Impact energy (max)	6 J
Vibration level (hammer drilling)	9 m/s²
Drilling diameter in concrete (max)	40 mm
Optimum drilling diameter (concrete)	16 - 32 mm
Input power	1100 W
Power source	AC
Power plug type	Type C
Noise level	108 dB
Quantity per shipping (inner) case	1 pc(s)

Weight and Dimensions

Weight	6100 g
Package depth	3456 mm
Package width	2000 mm
Package height	4500 mm
Package weight	4500 g
