Hilti TE 50-AVR Operating Instructions

6 English 2126361
*2126361*
3.8 Items supplied
Combihammer, side handle, operating instructions.
Other system products approved for use with this product can be found at your local Hilti Store or at:
www.hilti.group
4 Technical data
4.1 Combihammer
For rated voltage, rated current, frequency and/or input power, refer to the country-specific type
identification plate.
If the device is powered by a generator or transformer, the generator or transformer’s power output must be
at least twice the rated input power shown on the rating plate of the device. The operating voltage of the
transformer or generator must always be within +5 % and -15 % of the rated voltage of the device.
TE 50AVR
Weight in accordance with EPTA procedure 01
6.1 kg
Storage temperature
−20 ℃ … 70 ℃
Ambient temperature for operation
−17 ℃ … 60 ℃
Ø hammer drill bits
12 mm … 32 mm
Ø drill bits for wood
6 mm … 35 mm
Ø drill bits for metal
6 mm … 13 mm
4.2 Noise information and vibration values in accordance with EN 62841
The sound pressure and vibration values given in these instructions were measured in accordance with a
standardized test and can be used to compare one power tool with another. They can also be used for a
preliminary assessment of exposure.
The data given represent the main applications of the power tool. However, if the power tool is used for
different applications, with different accessory tools, or is poorly maintained, the data can vary. This can
significantly increase exposure over the total working period.
An accurate estimation of exposure should also take into account the times when the power tool is switched
off, or when it is running but not actually being used for a job. This can significantly reduce exposure over
the total working period.
Identify additional safety measures to protect the operator from the effects of noise and/or vibration, for
example: maintaining the power tool and accessory tools, keeping the hands warm, organization of work
patterns.
Noise emission values
TE 50AVR
Sound (power) level (L
WA
)
108 dB(A)
Uncertainty for the sound power level (K
WA
)
3 dB(A)
Sound pressure level (L
pA
)
97 dB(A)
Uncertainty for the sound pressure level (K
pA
)
3 dB(A)
Total vibration
TE 50AVR
Drilling in metal (a
h,D
)
< 5 m/s²
Hammer drilling in concrete (a
h,HD
)
8.8 m/s²
Chiseling (a
h,Cheq
)
7.1 m/s²
Uncertainty for the given vibration value (K)
1.5 m/s²

Hilti TE 50-AVR Specifications

General

Drilling	Yes
Chuck type	SDS Max
Product color	Black, Red
Country of origin	Germany
Impact rate	3180 bpm
Rated speed (max)	360 RPM
Impact energy (max)	6 J
Vibration level (hammer drilling)	9 m/s²
Drilling diameter in concrete (max)	40 mm
Optimum drilling diameter (concrete)	16 - 32 mm
Input power	1100 W
Power source	AC
Power plug type	Type C
Noise level	108 dB
Quantity per shipping (inner) case	1 pc(s)

Weight and Dimensions

Weight	6100 g
Package depth	3456 mm
Package width	2000 mm
Package height	4500 mm
Package weight	4500 g
