Hilti TE 7-C Manual

ﻋﺮﺑﻲ 99
3ﺍﻟﺸﺮﺡ
3.1ﻧﻈﺮﺓﻋﺎﻣﺔﻋﻠﻰﺍﻟﻤﻨﺘﺞ1
@
ﻏﻄﺎءﺍﻟﺤﻤﺎﻳﺔﻣﻦﺍﻟﻐﺒﺎﺭ
;
ﻇﺮﻑﺗﺮﻛﻴﺐﺍﻷﺩﻭﺍﺕTE-C Click
=
ﻣﻔﺘﺎﺡﺍﺧﺘﻴﺎﺭﺍﻟﻮﻇﻴﻔﺔ
%
ﻣﻔﺘﺎﺡﺍﻟﺘﺤﻜﻢ
&
ﺍﻟﻤﻘﺒﺾ
(
ﻣﻔﺘﺎﺡﺗﺤﻮﻳﻞﺍﻟﺪﻭﺭﺍﻥﺟﻬﺔﺍﻟﻴﻤﻴﻦ/ﺍﻟﻴﺴﺎﺭ
)
ﻛﺎﺑﻞﺍﻟﻜﻬﺮﺑﺎء
+
ﻭﺻﻠﺔﻭﺣﺪﺓﺍﻟﺤﻤﺎﻳﺔﻣﻦﺍﻟﻐﺒﺎﺭTE DRS-M
§
ﻣﻘﺒﺾﺟﺎﻧﺒﻲﻣﺰﻭﺩﺑﻤﺤﺪﺩﻋﻤﻖﺍﻟﺜﻘﺐ
3.2ﺍﻻﺳﺘﺨﺪﺍﻡﺍﻟﻤﻄﺎﺑﻖﻟﻠﺘﻌﻠﻴﻤﺎﺕ
ﺍﻟﻤﻨﺘﺞﺍﻟﻤﺸﺮﻭﺡﻋﺒﺎﺭﺓﻋﻦﻣﺜﻘﺎﺏﻣﻄﺮﻗﻲﻣﺸﻐﻞﺑﺎﻟﻜﻬﺮﺑﺎء.ﺍﻟﺠﻬﺎﺯﻣﺨﺼﺺﻷﻋﻤﺎﻝﺍﻟﺜﻘﺐﻓﻲﺍﻟﺨﺮﺳﺎﻧﺔﻭﺍﻟﺠﺪﺭﺍﻥ
ﻭﺍﻟﻤﻼﻁﺍﻟﺠﺼﻲﻭﺍﻟﺨﺸﺐﻭﺍﻟﺒﻼﺳﺘﻴﻚﻭﺍﻟﻤﻌﺎﺩﻥ.ﻋﻼﻭﺓﻋﻠﻰﺫﻟﻚﻳﻤﻜﻦﺍﺳﺘﺨﺪﺍﻡﺍﻟﻤﺜﻘﺎﺏﺍﻟﻤﻄﺮﻗﻲﻓﻲ
ﺍﻷﻋﻤﺎﻝﺍﻟﺨﻔﻴﻔﺔﺍﻟﺘﻲﻳﺘﻢﻓﻴﻬﺎﺍﺳﺘﺨﺪﺍﻡﺍﻹﺯﻣﻴﻞﻟﻠﻨﻘﺮﻓﻲﺍﻟﺠﺪﺭﺍﻥﻭﺍﻷﻋﻤﺎﻝﺍﻟﻼﺣﻘﺔﺍﻟﺘﻲﺗﺘﻢﻋﻠﻰﺍﻟﺨﺮﺳﺎﻧﺔ.
◀
ﻳﺠﺐﺃﻻﻳﺘﻢﺍﻟﺘﺸﻐﻴﻞﺇﻻﺑﺎﻟﺘﺮﺩﺩﻭﺍﻟﺠﻬﺪﺍﻟﻜﻬﺮﺑﺎﺋﻲﺍﻟﻤﺬﻛﻮﺭﻳﻦﻋﻠﻰﻟﻮﺣﺔﺍﻟﺼﻨﻊ.
3.3ﻣﺠﻤﻮﻋﺔﺍﻟﺘﺠﻬﻴﺰﺍﺕﺍﻟﻤﻮﺭﺩﺓ
ﺍﻟﻤﺜﻘﺎﺏﺍﻟﻤﻄﺮﻗﻲ،ﺍﻟﻤﻘﺒﺾﺍﻟﺠﺎﻧﺒﻲ،ﻣﺤﺪﺩﺍﻟﻌﻤﻖ،ﺩﻟﻴﻞﺍﺳﺘﻌﻤﺎﻝ.
ﺗﺠﺪﺍﻟﻤﺰﻳﺪﻣﻦﻣﻨﺘﺠﺎﺕﺍﻟﻨﻈﺎﻡﺍﻟﻤﺴﻤﻮﺡﺑﻬﺎﻟﻤﻨﺘﺠﻚﻟﺪﻯﻣﺘﺠﺮHilti Storeﺃﻭﻋﻠﻰﻣﻮﻗﻊﺍﻹﻧﺘﺮﻧﺖ:
www.hilti.group|ﺍﻟﻮﻻﻳﺎﺕﺍﻟﻤﺘﺤﺪﺓﺍﻷﻣﺮﻳﻜﻴﺔ:www.hilti.com
4ﺍﻟﻤﺜﻘﺎﺏﺍﻟﻤﻄﺮﻗﻲ
ﻣﻠﺤﻮﻇﺔ
ﻳﺮﺟﻰﺍﻟﺘﻌﺮﻑﻋﻠﻰﺍﻟﺠﻬﺪﺍﻻﺳﻤﻲﻭﺍﻟﺘﻴﺎﺭﺍﻻﺳﻤﻲﻭﺍﻟﺘﺮﺩﺩﻭ/ﺃﻭﺍﻻﺳﺘﻬﻼﻙﺍﻻﺳﻤﻲﻣﻦﻟﻮﺣﺔﺻﻨﻊﺍﻟﺠﻬﺎﺯ
ﺍﻟﺨﺎﺻﺔﺑﺎﻟﺒﻠﺪﺍﻟﻤﻌﻨﻲ.
ﻓﻲﺣﺎﻟﺔﺍﻟﺘﺸﻐﻴﻞﻣﻦﻣﻮﻟﺪﺃﻭﻣﺤﻮﻝ،ﻓﺈﻧﻪﻳﺠﺐﺃﻻﺗﻘﻞﻗﺪﺭﺓﺍﻟﺨﺮﺝﺍﻟﺨﺎﺻﺔﺑﻪﻋﻦﺿﻌﻒﻗﺪﺭﺓﺍﻟﺪﺧﻞ
ﺍﻻﺳﻤﻴﺔﺍﻟﻮﺍﺭﺩﺓﻋﻠﻰﻟﻮﺣﺔﺻﻨﻊﺍﻟﺠﻬﺎﺯ.ﺟﻬﺪﺗﺸﻐﻴﻞﺍﻟﻤﺤﻮﻝﺃﻭﺍﻟﻤﻮﻟﺪﻳﺠﺐﺃﻥﻳﻜﻮﻥﺩﺍﺋﻤﺎﻓﻲﻧﻄﺎﻕ+5%ﻭ
-15%ﻣﻦﺍﻟﺠﻬﺪﺍﻟﻜﻬﺮﺑﺎﺋﻲﺍﻻﺳﻤﻲﻟﻠﺠﻬﺎﺯ.
ﺍﻟﻤﺜﻘﺎﺏﺍﻟﺪﻗﺎﻕ
TE 7C
ﺍﻟﻮﺯﻥﻃﺒﻘﺎﻟﺒﺮﻭﺗﻮﻛﻮﻝEPTA 01
3.5ﻛﺠﻢ
Øﺭﻳﺸﺔﺛﻘﺐﺩﻗﺎﻗﺔ
5ﻣﻢ…28ﻣﻢ
Øﺭﻳﺸﺔﺛﻘﺐﺍﻟﺨﺸﺐ
3ﻣﻢ…20ﻣﻢ
Øﺭﻳﺸﺔﺛﻘﺐﺍﻟﻤﻌﺎﺩﻥ
≥13ﻣﻢ
4.1ﻗﻴﻢﺍﻟﻀﻮﺿﺎءﻭﺍﻻﻫﺘﺰﺍﺯﻃﺒﻘﺎﻟﻠﻤﻮﺍﺻﻔﺔEN 60745
ﺗﻢﻗﻴﺎﺱﺿﻐﻂﺍﻟﺼﻮﺕﻭﻗﻴﻢﺍﻻﻫﺘﺰﺍﺯﺍﻟﻮﺍﺭﺩﺓﻓﻲﻫﺬﺍﺍﻟﺪﻟﻴﻞﻃﺒﻘﺎﻷﺣﺪﻣﻌﺎﻳﻴﺮﺍﻟﻘﻴﺎﺱﺍﻟﻤﺤﺪﺩﺓﻭﻳﻤﻜﻦ
ﺍﻻﺳﺘﻌﺎﻧﺔﺑﻬﺎﻓﻲﺇﺟﺮﺍءﻣﻘﺎﺭﻧﺔﺑﻴﻦﺍﻷﺩﻭﺍﺕﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔﻣﻊﺑﻌﻀﻬﺎﺍﻟﺒﻌﺾ.ﻭﻫﻲﻣﻨﺎﺳﺒﺔﺃﻳﻀﺎﻟﺘﻘﺪﻳﺮﺣﺠﻢﺍﻟﻤﺨﺎﻃﺮ
ﺑﺼﻮﺭﺓﺃﻭﻟﻴﺔ.
ﺍﻟﻤﻮﺍﺻﻔﺎﺕﺍﻟﻮﺍﺭﺩﺓﺗﺘﻌﻠﻖﺑﺎﻻﺳﺘﺨﺪﺍﻣﺎﺕﺍﻷﺳﺎﺳﻴﺔﻟﻸﺩﺍﺓﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ.ﺃﻣﺎﺇﺫﺍﺗﻢﺍﺳﺘﺨﺪﺍﻡﺍﻷﺩﺍﺓﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ
ﻓﻲﺗﻄﺒﻴﻘﺎﺕﺃﺧﺮﻯﻣﻊﺃﺩﻭﺍﺕﺷﻐﻞﻣﺨﺎﻟﻔﺔﻟﻠﻤﻮﺍﺻﻔﺎﺕﺃﻭﺩﻭﻥﺻﻴﺎﻧﺔﻛﺎﻓﻴﺔ،ﻓﻔﻲﻫﺬﻩﺍﻟﺤﺎﻟﺔﻗﺪﺗﺨﺘﻠﻒ
ﺍﻟﻤﻮﺍﺻﻔﺎﺕ.ﻭﻗﺪﻳﺰﻳﺪﻫﺬﺍﻣﻦﻧﺴﺒﺔﺍﻟﻤﺨﺎﻃﺮﻃﻮﺍﻝﻣﺪﺓﺍﻟﻌﻤﻞﺑﺼﻮﺭﺓﻭﺍﺿﺤﺔ.
ﻭﻟﻠﺤﺼﻮﻝﻋﻠﻰﺗﻘﺪﻳﺮﺩﻗﻴﻖﻟﺤﺠﻢﺍﻟﻤﺨﺎﻃﺮﻳﻨﺒﻐﻲﺃﻳﻀﺎﻣﺮﺍﻋﺎﺓﺍﻷﻭﻗﺎﺕﺍﻟﺘﻲﻳﺘﻢﻓﻴﻬﺎﺇﻳﻘﺎﻑﺍﻟﺠﻬﺎﺯﺃﻭﺍﻟﺘﻲﻳﺘﻢﻓﻴﻬﺎ
ﺗﺸﻐﻴﻞﺍﻟﺠﻬﺎﺯﻭﻟﻜﻦﺩﻭﻥﺍﺳﺘﺨﺪﺍﻡﺣﻘﻴﻘﻲ.ﻭﻗﺪﻳﻘﻠﻞﻫﺬﺍﻣﻦﻧﺴﺒﺔﺍﻟﻤﺨﺎﻃﺮﻃﻮﺍﻝﻣﺪﺓﺍﻟﻌﻤﻞﺑﺼﻮﺭﺓﻭﺍﺿﺤﺔ.
ﺍﺣﺮﺹﻋﻠﻰﺍﺗﺨﺎﺫﺇﺟﺮﺍءﺍﺕﺇﺿﺎﻓﻴﺔﻟﻠﺴﻼﻣﺔﻣﻦﺷﺄﻧﻬﺎﺣﻤﺎﻳﺔﺍﻟﻤﺴﺘﺨﺪﻡﻣﻦﺗﺄﺛﻴﺮﺍﻟﻀﺠﻴﺞﻭ/ﺃﻭﺍﻻﻫﺘﺰﺍﺯﺍﺕﻣﺜﻞ:
ﺻﻴﺎﻧﺔﺍﻷﺩﺍﺓﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔﻭﺃﺩﻭﺍﺕﺍﻟﺸﻐﻞﻭﺍﻟﺤﻔﺎﻅﻋﻠﻰﺍﻷﻳﺪﻱﻓﻲﺣﺎﻟﺔﺩﺍﻓﺌﺔﻭﺗﻨﻈﻴﻢﻣﺮﺍﺣﻞﺍﻟﻌﻤﻞ.
ﻣﻌﻠﻮﻣﺎﺕﺍﻟﻀﺠﻴﺞ
ﻣﺴﺘﻮﻯﺷﺪﺓﺍﻟﺼﻮﺕ)L
WA
(
100ﺩﻳﺴﻴﺒﻞ)A(
ﻧﺴﺒﺔﺍﻟﺘﻔﺎﻭﺕﻟﻤﺴﺘﻮﻯﺷﺪﺓﺍﻟﺼﻮﺕ)K
WA
(
3ﺩﻳﺴﻴﺒﻞ)A(
Printed: 10.10.2017 | Doc-Nr: PUB / 5071226 / 000 / 06

Hilti TE 7-C Specifications

General

Impact energy (max)	2.6 J
Sound pressure level	89 dB
Vibration level (hammer drilling)	17 m/s²
Drilling diameter in concrete (max)	16 mm
Reverse	Yes
Power source	AC

Weight and Dimensions

Depth	343 mm
Width	86 mm
Height	215 mm
Weight	3400 g
