The tool is designed for the following uses:
Use Required insert tools Diameter range
TE 2 / TE 2-E / TE 2-S / TE 2-M:
Hammer drilling in concrete, Drill bits with TE-C connection end Drilling in concrete:
masonry and natural stone – Short hammer drill bits Anchor holes of 4–22 mm dia.
– Long hammer drill bits Through holes of 4–22 mm dia.
TE 2-S:
Drilling with precision Drill bits with TE-C connection end Drilling in brittle materials:
hammering action in perforated – TE-C hammer drill bits Anchor holes of 4–22 mm dia.
brick, tiles and marble – Thin-barrel core bits Cutting sockets of 25–68 mm dia.
TE 2 / TE 2-E / TE 2-S:
Drilling in wood, drywall panels Quick-release chuck
and metal with TE-C adaptor
for insert tools
with cylindrical shank or hexagonal shank
for rotary-only drilling
Wood drill bits 4–20 mm dia.
Metal drill bits 3–13 mm dia.
Hole saws 25–68 mm dia.
TE 2-M:
Drilling in wood, drywall panels, Interchangeable quick-release chuck
tiles and metal for insert tools
with cylindrical shank or hexagonal
shank for rotary-only drilling:
Wood drill bits 4–10 mm dia. in 2nd gear
10–20 mm dia. in 1st gear
Metal/stepped drill bits 3– 8 mm dia. in 2nd gear
8–13 mm dia. in 1st gear
Hole saws 25–68 mm dia. in 1nd gear
– The tool is intended for professional use.The tool
may be operated, serviced and repaired only by
authorized, trained personnel. This personnel must
be informed of any special hazards that may be
encountered.
Main features of the tool
Class II electrical protection (double insulated) Z
Mechanical torque-limiting clutch
Grip and side handle with vibration absorption
TE-C chuck
TE-C insert tool system
Variable speed switch
Rotary-only drilling mode
Gearing and hammering mechanism with permanent
grease lubrication
Pivotable side handle (360°)
Mechanical depth gauge
Interface for quick-release chuck (TE 2-M)
Precision hammering action (TE 2-S)
High spindle speed without hammering action (TE 2-M)
Lockbutton for sustained operation
Right of technical changes reserved
02_BA_TE2_S_M_P1_en.qxd 31.08.2007 10:39 Uhr Seite 12

Hilti TE2 Specifications

General

Dust Removal Module Available	Yes
Rated Voltage	230 V
Hammer Drilling Diameter Range	5 - 22 mm
Functionality	Hammer drilling, drilling
Tool Holder	SDS-plus
