Hilti TE2 User Manual

19
en
Troubleshooting
Symptom Possible cause Possible solution
The tool doesn’t start Fault in the electric power supply Plug in another electric tool and check
whether it starts
Defective supply cord or plug Have it checked by an electrical
specialist and replace if necessary
Switch defective Have it checked by an electrical
specialist and replace if necessary
No hammering action The tool is too cold Allow tool to reach the minimum
operating temperature
See section “Before use”
Function selection switch Set function selection switch to
set to rotary drilling hammer drilling
Tool doesn’t produce full Cross-section of the Use an extension cord of adequate cross-
power extension cord is inadequate sectional area. See section “Before use”
Control switch is not pressed fully Press the control switch as far as it will go
Function selection switch set Set function selection switch
to precision hammering action to hammer drilling
Forwards / reverse switch set Set forwards / reverse switch
to reserve when drilling to forwards
Drill bit cannot be released Chuck not opened fully Pull the chuck locking sleeve back as
far as it will go and remove the insert
tool
EC declaration of conformity
Description: Rotary Hammer
Designation: TE2 / TE 2-E / TE2-S / TE2-M
Year of design: 2005
We declare, under our sole responsibility, that this product
complies with the following directives and standards:
89/336/EWG, 98/37/EG, EN 55014-1, EN 55014-2,
EN 60745-1, EN 60745-2-6, EN 61000-3-2, EN 61000-3-3
Hilti Corporation
Peter Cavada Matthias Gillner
Head of BU Head of BA
Quality and Process Management Electric Tools & Accessories
BA Electric Tools & Accessories
11/2006 11/2006
02_BA_TE2_S_M_P1_en.qxd 31.08.2007 10:39 Uhr Seite 19

Hilti TE2 Specifications

General

Dust Removal Module Available	Yes
Rated Voltage	230 V
Hammer Drilling Diameter Range	5 - 22 mm
Functionality	Hammer drilling, drilling
Tool Holder	SDS-plus
