13
en
Technical data
Rated power 650 W
Nominal voltage ✱ 100 V 110 V 120 V 220 V 230 V 240 V
Nominal current input ✱ 6.9 A 6.5 A 6.1 A 3.1 A 3.0 A 2.9 A
Mains frequency 50–60 Hz
Weight of tool without side handle 2.4 kg (TE2 / TE2-S / TE2-E)
2.7 kg (TE2-M)
Weight as per EPTA-Procedure 01/2003 2.7 kg (TE2 / TE2-S / TE2-E)
2.9 kg (TE2-M)
Dimensions (l×h×w) 352×203×89 mm (TE2 / TE 2-E / TE 2-S)
360×203×89 mm (TE2-M)
Minimum distance between wall and hole drilled 34 mm
Speed 0– 930 r.p.m. (hammer drilling)
0–1200 r.p.m. (in 1st gear TE 2 / TE 2-E / TE 2-S / TE 2-M)
0–2500 r.p.m. (in 2nd gear TE2-M)
Hammering speed:
Precision hammering action 0–2600 blows/min. (TE 2-S)
Full hammering action 0–4600 blows/min. (TE 2 / TE 2-E / TE 2-S / TE 2-M)
Single impact energy Nm (J):
Precision hammering action 0.6 Nm (TE 2-S)
Full hammering action 1.8 Nm (TE 2 / TE 2-E / TE 2-S / TE 2-M)
Typical drilling performance in medium-hard B35 8 mm dia.: 550 mm/min
concrete 10 mm dia.: 500 mm/min
12 mm dia.: 400 mm/min
Noise and vibration information (measured in accordance with EN 60745-2-6 prAB: 2005):
Typical A-weighted sound power level (LwA): 102 dB (A)
Typical A-weighted emission sound power level (LpA): 91dB (A)
For the given sound power level
as per EN 60745, the tolerance is 3 dB
Wear ear protection!
Triaxial vibration value (vibration vector sum)
measured in accordance with EN 60745-2-1 prAA: 2005
Drilling in metal, (a
h, D
) .2.8 m/s
2
measured in accordance with EN 60745-2-6 prAB: 2005
Hammer drilling in concrete, (a
h, HD
) 13.5 m/s
2
Uncertainty (K) for triaxial vibration value 1.5 m/s
2
✱ The tool is offered in different versions for various mains voltages. Please refer to the information on the
type plate for the nominal voltage and nominal current input of your tool.
02_BA_TE2_S_M_P1_en.qxd 31.08.2007 10:39 Uhr Seite 13
