CEA7 CONTROL UNIT INPUTS AND OUTPUTS | PAGE 26
ELECTRONIC PROTECTION OUTPUT (SC). DIGITAL OUTPUT
The electronic protection output (SC) is activated when any alarm that stops the
engine is detected. The output remains activated until all the alarms that cause
the engine to stop disappear and are reported.
The programming of the SC output may be assigned to any of the functions of the
programmable outputs (Settings table, parameter 24). In this case, the default
function of the output is disabled.
5.6 PROGRAMMABLE OUTPUTS
The CEA7 control unit has 3 programmable outputs with operation which can be
congured to indicate certain states (Settings table, parameters 1 to 3). The
possible congurations that are permitted with the programmable outputs are:
INHIBITED OUTPUT
The programmable outputs congured as inhibited output do not respond to any
action or state as they are permanently disabled.
OUTPUT PROGRAMMED ACCORDING TO THE STATE OF AN INPUT
The programmable outputs (associated with a programmable input) are activated
when an associated input is detected. Possible congurations of associated
inputs include the following values:
Fuel reserve input.
Water level input.
Programmable input 1.
Programmable input 2.
Programmable input 3.
Programmable input 4.
Programmable input 5.
PROGRAMMED OUTPUT FOR ALARM
The programmable outputs congured as a programmed output for alarm is
activated when the control unit detects an active alarm associated to a
programmable output or has not still not been notied by the user.
Control unit errors. Given an error which is active or pending notication
by the user, control unit alarm output is activated for a maximum
programmable time (Times table, parameter 14). The errors that
activate the AL output are both alarms that cause the engine to stop
and warnings that do not cause the engine to stop. Depending on how
the AL output has been programmed (Regulations table, parameter 31,
acoustic alarm eld):
For an AL outlet that has been programmed as an AL acoustic
signal (Regulations table, parameter 31, acoustic alarm, eld value
0), when the user presses the RESET key:
- Continuous activation of the AL output (value 0 in Times table,
parameter 14): the AL output is disabled, providing there is no
active error or warning.
- Timed activation (value in seconds of the activation of the output
in the Times table, parameter 14): the AL output is disabled
the rst time the RESET key is pressed or once the output
activation time is exceeded.
When the AL output is programmed to signal errors (Regulations
table, parameter 31, acoustic alarm eld, value 1), when the user
presses the RESET key, the buzzer of the interface is disabled but
the AL output activation is maintained as long as any active genset
alarm remains in effect or pending notication.
The programming of the AL output can be assigned to any of the functions of the
programmable outputs (Settings table, parameter 41). In this case, the default
function of the output is disabled.
STARTED ENGINE OUTPUT (MA). DIGITAL OUTPUT
The started engine output (MA) of the CEA7 control unit is activated when any
started engine condition is detected and remains active while the engine is
running. The started engine output (MA) is deactivated as soon as the engine
stopping process begins; said process includes the engine cooling interval
(Times table, parameter 11) during the stopping process.
The programming of the MA output may be assigned to any of the functions of
the programmable outputs (Settings table, parameter 42). In this case, the de-
fault function of the output is disabled.
