(APPENDIX I) PARAMETERS TABLE | PAGE 72
Contents Alarm
81 Busbar voltage (CEP7 control units only)
82 Gensets present (CEP7 control units only)
83 Neutral intensity (CEP7/CES7 control units only)
84 Genset identier (CEP7 control units only)
85 Vector jump (CEP7/CES7 control units only)
86 ROCOF (CEP7/CES7 control units only)
87 IDMT
88 TEMPERATURE PROBE 5
89 TEMPERATURE PROBE 6
90 TEMPERATURE PROBE 7
91 TEMPERATURE PROBE 8
92 TEMPERATURE PROBE 5 Level 2
93 TEMPERATURE PROBE 6 Level 2
94 TEMPERATURE PROBE 7 Level 2
95 TEMPERATURE PROBE 8 Level 2
99 PROGRAMMABLE 6
100 PROGRAMMABLE 7
101 PROGRAMMABLE 8
102 PROGRAMMABLE 9
103 PROGRAMMABLE 10
104 PROGRAMMABLE 11
105 PROGRAMMABLE 12
106 PROGRAMMABLE 13
107 PROGRAMMABLE 14
108 PROGRAMMABLE 15
109 PROGRAMMABLE 16
110 PROGRAMMABLE 17
111 PROGRAMMABLE 18
112 PROGRAMMABLE 19
113 PROGRAMMABLE 20
114 Low genset power
115 Current asymmetry
116 Water in fuel
117..130 Reserved
Tabla 13
Parameters clearance selector Table
Parameter PSW Description
Default
value
Range
1 2 Signal type clearance 1 1
0- Three-phase
without neutral
1- Three-phase
2- Two-phase
3- Single-phase
4- Delta with
neutral
5- Delta without
neutral
6- Two-phase
selector
2 2 Maximum Unit Voltage clearance 1 440V
3 2 Minimum Unit Voltage clearance 1 360V
4 2 Maximum generator current clearance 1 1000A
5 2 Short circuit detection clearance 1 3000A
6 2 Maximum Unit Frequency clearance 1 58Hz
7 2 Minimum Unit Frequency clearance 1 45Hz
8 2 Signal type clearance 2 1
0- Three-phase
without neutral
1- Three-phase
2- Two-phase
3- Single-phase
4- Delta with
neutral
5- Delta without
neutral
6- Two-phase
selector
9 2 Maximum Unit Voltage clearance 2 440V
10 2 Minimum Unit Voltage clearance 2 360V
11 2 Maximum generator current clearance 2 1000 Amps
12 2 Short circuit detection clearance 2 3000 Amps
13 2 Maximum Unit Frequency clearance 2 58Hz
14 2 Minimum Unit Frequency clearance 2 45Hz
15 2 Engine speed clearance 1 (only option J1939) 1500rpm 0..10000 rpm
16 2 Speed J1939 clearance 2 (only option J1939) 1500 rpm 0..10000 rpm
17 2 Nominal Power of the genset clearance 1 220 kW
18 2 Nominal Power of the genset clearance 2 220 kW
19
2
Minimum engine speed clearance 1
1350
20 2 Maximum engine speed clearance 1 1740
21 2 Minimum engine speed clearance 2 1350
22 2 Maximum engine speed clearance 2 1740
31 2 Maximum IDMT current – Set 1 0
32 2 Maximum IDMT current – Set 1 0
