(APPENDIX II) CONTROL UNIT SCREENS | PAGE 75
Tabla 1
Regeneration functionality icon table
DESCRIPCIÓN ICONO VALOR
DIESEL PARTICULATE FILTER
LAMP
SPN: 3697
OFF
ON
ON (blink).
FILTER PARTICULATE STATUS
SPN: 3701
Not required regeneration.
Required regeneration – Low level.
Required regeneration – High level (blink).
FILTER ACTIVE REGENERATION
STATUS
NORMAL SPN: 3700
Active regeneration.
REGENERATION
INHIBITED INTERLOCK SPN: 3702
INHIBITED SWITCH SPN: 3703
Inhibited regeneration by INTERLOCK.
Inhibited regeneration by switch (blink).
REGENERATION FORCED
SPN: 4175
Forced regeneration.
EXHAUST SYSTEM HIGH
TEMPERATURE
SPN: 3698
Exhaust system high temperature (blink).
NOTE
Regeneration icons only available for STAGE V/FINAL TIER 4 engines.
10.1.3 CONTROL UNIT STATUS SCREEN
1. Status of the programmable inputs
GENSET: STOPPED
START INHIBITED
Fig.2
CEM7 + CEC7
3. Measurements of V., A., NC., RPM., P., alternative display of voltages and
currents, NC fuel level, engine speed RPM. P actual power consumed.
GENERATOR:
10.1.2 ENGINE STATUS SCREEN
1. Measurements of RPM., H., NC., DI., TM., VB., PA., display of engine speed
RPM, H operating hours, NC fuel level, DI battery charging alternator voltage, TM
engine temperature, VB battery voltage, PA oil pressure and, either AA auxiliary
temperature or NC2 fuel level in auxiliary tank.
ENGINE
NOTE
To display the engine temperature and oil pressure, the engine must be provided
with appropriate sensors.
In the event the engine readings are conducted through the extension J1939,
the word ENGINE is replaced by the word J1939. Activation of the electronic
engine control is indicated by the ashing word J1939.
