(APPENDIX VII) CALIBRATION OF THE CONTROL UNIT | PAGE 105
13. APPENDIX V: CALIBRATION OF THE CONTROL
UNIT
The CEA7 control unit allows calibration adjustments to be made to the voltage
measurements of the genset and network (only control units CEA7 and CEC7).
For this purpose, it is enabled in the Parameters menuMeasurements of
parameters 3, 4 and 5 for calibrating the voltages R, S and T of the genset; also,
parameters 14, 15 and 16 are enabled for calibrating the voltages U, V and W of
the network (only control units CEA7 and CEC7). To carry out this process, the
enabling of a manufacturer level password is required.
* * * * PARAMETERS * * * *
1 . Measurements
2 . Times
3 . Regulations
To access the calibration process pressed the key to access the parameter
that calibrates the corresponding phase.
* * * * MEASUREMENTS * * * *
P 0 3 . . . . . . . . . . . 0
P 0 4 . . . . . . . . . . . 0
P 0 5 . . . . . . . . . . . 0
When entering calibration mode, the current voltage measurement between
phase and neutral of the corresponding phase is shown:
* * * * MEASUREMENTS * * * *
P 0 0 3 [ 2 2 7 ] . . . . . 0
P 0 0 4 . . . . . . . . . . 0
P 0 0 5 . . . . . . . . . . 0
Using the keys the voltage between phase and neutral measured by the
control unit is adjusted to match the actual value.
* * * * MEASUREMENTS * * * *
P 0 0 3 [ 2 2 3 ] . . . . . 4
P 0 0 4 . . . . . . . . . . 0
P 0 0 5 . . . . . . . . . . 0
Pressing the key completes the calibration process. The calibration process
can be interrupted by pressing the key
. Calibration of the system can be reset
by writing parameter 17 for the network voltage and parameter 18 for the genset
voltages.
