Chapter 1 Product Outline
10. Clamp sensor
To measure current, open the top ends of the clamp
sensor by gripping the lever 11. Then position the
conductor to be measured at the center of the clamp
sensor and firmly close the clamp sensor.
11. Lever
Used to open and close the clamp sensor.
12. Current direction mark
When measuring power, clamp the conductor with
the arrow facing the load side.
13. Data Output terminal
Connected to the optional 9636 RS-232C cable to
provide output.
14. Voltage measurement terminal
Connected to the 9635 test lead (red and black,
supplied with the unit) to measure voltage and
harmonic.
15. Back case
To replace the battery, remove the two screws.
16. Hand strap
Attach to get a better grip on the unit.
