Chapter 3 Specifications
Range
(Accuracy Range)
Resolution
Accuracy
30Hz to 1kHz
200A
(10.0Arms to 200.0Arms)
1A 3.0%rdg. 5dgt.
1000A
(100Arms to 1000Arms)
1A 3.0%rdg. 5dgt.
Range
(Accuracy Range)
Resolution
Accuracy
45Hz to 66Hz
30Hz to 45Hz,
66Hz to 1kHz
150.0V
(10.0rmsV to 150.0rmsV)
0.1V 1.0%rdg. 3dgt. 1.5%rdg. 5dgt.
300.0V
(30.0rmsV to 300.0rmsV)
0.1V 1.0%rdg. 3dgt. 1.5%rdg. 5dgt.
600V
(60rmsV to 600rmsV)
1V 1.0%rdg. 3dgt. 1.5%rdg. 5dgt.
Range
(Accuracy Range)
Resolution
Accuracy
30Hz to 1kHz
150V
(10.0Vrms to 150.0Vrms)
1V 3.0%rdg. 5dgt.
300V
(30.0Vrms to 300.0Vrms)
1V 3.0%rdg. 5dgt.
600V
(60Vrms to 600Vrms)
1V 3.0%rdg. 5dgt.
3.1.2 AC Volta
g
e Measurement S
p
ecifications
AC current (wave peak value) I
PEAK
AC voltage (true rms) U
RMS
AC voltage (wave peak value) U
PEAK
