45
Chapter 3 Specifications
Measurement
accuracy
Harmonic levels
Order Accuracy
1 3.0%rdg. 10dgt.
2to6 3.5%rdg. 10dgt.
7to8 4.5%rdg. 10dgt.
9to10 5.0%rdg. 10dgt.
11 to 15 7.0%rdg. 10dgt.
16 to 20 10%rdg. 10dgt.
Harmonic
percentage
Total harmonic
distortion ratio
1 dgt. with respect to calculation from
each measured value.
1 dgt. with respect to calculation from
each measured value.
Operating system Digital sampling system
Phase detection system
Single-phase Power
Measurement
Power Factor & Phase
Angle Measurement
Waveform Digital sampling -
Phase - Phase detection
Three-phase Power
Measurement
Harmonic
Measurement Function
Waveform Digital sampling Digital sampling
Phase Phase detection -
Accessory Functions:
Phase detection (at 3-
phase balanced load)
Normal/ Reverse/ Missing
(50/60 Hz, sine wave)
Recording Maximum (MAX) and minimum (MIN)
values display selectable for current,
voltage, and effective / apparent power
measurements
Data hold Data hold function
3.2 General Specifications
