9.1 Basic Specifications
182
Voltage measurement BT3561A, BT3562 : 6 V/ 60 V 2 ranges
BT3562A : 6 V/ 60 V/ 100 V 3 ranges
BT3563A, BT3563 : 6 V/ 60 V/ 300 V 3 ranges
Auto-range function Yes (applies to both resistance and voltage measurement.)
Measurement Ranges
Measurement Value Display
Display count value Resistance measurement : “-1000 to 31000”
Voltage measurement : “-600000 to 600000” (6 V/ 60 V ranges)
“-100000 to 100000” (100 V range)
“-300000 to 300000” (300 V range)
Overflow display OF indicates a measurement exceeds display count value
-OF indicates a measurement is below display count value
Measurement fault
detection
(contact check)
Detected information: SOURCE HIGH-LOW connection faults
SENSE HIGH-LOW connection faults
Display: ”- - - - -”
Sampling Time
Sampling rate EX.FAST/ FAST/ MEDIUM/ SLOW (four steps)
Sampling time
• Tolerance for SLOW sampling is ± 5 ms, and ± 1 ms for other sampling rates
• Values within parentheses are power supply frequency settings
* When the measurement current mode is set to pulse while using the instru-
ment with an external trigger source or with continuous measurement set to
"Off," 1 ms is added for
V function measurement, and 4 ms is added for
function and V function measurement.
Response Time
Response time Measurement response time: Approx. 10 ms
The time from the moment the probes contact the test object in the open
state until the signal stabilizes within the measurement accuracy in the
internal measurement circuit (analog response time)
*Response time is given as a reference value based on pure resistance
measurement.
Actual values depend on the impedance characteristics of the object
being measured.
Total measurement time
Overall time required for measurement: Response time + Sampling time
Sampling EX.FAST FAST MEDIUM SLOW
V (50 Hz)
(60 Hz)
8 ms 24 ms
84 ms
70 ms
259 ms
253 ms
(50 Hz)
(60 Hz)
4 ms 12 ms
42 ms
35 ms
157 ms
150 ms
V (50Hz)
(60Hz)
4 ms 12 ms
42 ms
35 ms
157 ms
150 ms
