6.2 Selecting the Interface
93
6
Chapter 6 Printing
6.2 Selecting the Interface
1
(SHIFT Lamp lit)
The Menu display appears.
2
Select the Interface Selection display.
See "1.4 Menu Display Sequence (SHIFT ENTER)" (p.16).
Select Printer on the Sub Display.
rS ............ RS-232C
LAn......... LAN
GP-Ib...... GP-IB
Prn.......... Printer
3
Set the print interval time.
0000 .........................Interval printing is OFF. (Printing is carried out once when
PRINT key is pressed.)
0001 to 3600 ............Sets the print interval time in seconds.
4
Applies setting and returns to the Measurement display.
(Main Display)
(Sub Display)
The current setting blinks.
Or
numeric keypads
HIOKI BT3562A981-09
