Max., Min., Average, and Peak Values (MAX, MIN)
Max., Min., Average, and Peak Values (MAX, MIN)
The instrument can display the maximum, minimum, average, highest peak, or lowest peak values
of the measured data. The auto power save function is disabled.
1
Clamp the instrument around an object to be measured.
2
Press the RANGE key switch the range.
If you switch from the auto range to MAX or MIN mode, the range is xed at the presently set
range.
3
Press the MAX/MIN key.
Every time you press the key, another item is displayed.
MIN AVG PEAK MAX PEAK MIN
Presently measured value
(To cancel, hold down the MAX/MIN key for 1 s or more.)
• To freeze the readouts, press the HOLD key.
• The instrument measures the RMS value. AVG means the average value of all
measured values.
Peak max.
Peak min.
Max.
Display refresh interval
Waveform
Measured value
(RMS value)
Min.
