Hioki CM4001 - Comparator Function

13
Comparator Function (COMP)
Comparator Function (COMP)
When a measured value exceeds the threshold value, a buzzer sounds and the warning backlight
(p. 16) lights up.
You can also disable the buzzer sound.
The auto range cannot be used when the comparator function is enabled.
1
Hold down the key for 1 s or more.
The comparator function is enabled.
(To cancel, hold down the key for 1 s or more.)
2
Press the MAX/MIN key or RANGE key to set the threshold value.
Holding down the key increases or decreases the value continuously.
3
Press the HOLD key.
The threshold value is conrmed, and the instrument displays the measurement screen.
Video
Find issues faster with a comparator function on YouTube
HIOKI CM4001A963-00
