17
Parts Names and Functions
14
Measurement
terminal H(C)
Connect red cable.
15
Explanation label Contains brief instructions and the
instrument’s specications.
Back
16
17
18
16
Battery cover screw Binding head screw M3×6
17
Battery cover Remove this cover for replacing the batteries.
18
Serial number label Do not remove the label as it is needed for
product control such as product warranty etc.
1
2
3
4
5
6
7
Appx. Ind.
