Hioki IM3523A User Manual

6.5 Setting Application Settings
269
6
Chapter 6 Continuous Measurement Function
Set the draw timing for during continuous measurement.
If the display timing is set to , the time for continuous measurement becomes long because the
screen is updated every time measurement is performed.
If it is set to to give priority to the measurement time, the screen update time becomes short.
6.5 Setting Application Settings
CONTINUOUS
6.5.1 Setting the Display Timing
Procedure
Continuous Measurement Initial Screen Application Settings
1
Press .
2
Application Settings
4
Press to close the setting screen.
3
Draw Timing Setting
Set the timing for display.
Sequentially draws after measurement of
each panel.
Draws all after continuous measurement is
finished.
