Hirschmann GRS103-22TX/4C-2HV-2A User Manual

Installation GRS103
Release 01 03/2022
29
5.2.3 Rear view
5.2.4 Port assignment
1 Power supply unit 1
Table 7: Rear view: Device variants with non-redundant power supply
1 Power supply unit 2
2 Power supply unit 1
Table 8: Rear view: Device variants with redundant power supply
Table 9: Port assignment: Front view; numbering sequence identical for all device
variants
1
1 2
2.1
2.3
2.5
2.7
2.2 2.4
2.6 2.8
3.1 3.3 3.5 3.7
3.2 3.4 3.6
3.8
USB
MAC address
Status
P
ACA
1.1
1.2
1.5 1.7 1.9
1.6 1.8
1.10
1.3
1.4
Relay
PG I PG II
PG III
