Installation GRS103
Release
01
03/2022
65
12.4 Signal contact
12.5 Climatic conditions during operation
12.5.1 Basic device
12.5.2 Media modules
Nominal value Switching current max. 1 A
Switching voltage max. 60 V DC or max. 30 V AC SELV
according to IEC 60950-1 or ES1
according to IEC/EN 62368-1
Connection type 2-pin terminal block with screw lock
Tightening torque 0.34 Nm (3 lb-in)
min. conductor diameter 0.08 mm² (AWG28)
max. conductor diameter AWG16 (1.3 mm²)
Table 17: Signal contact
Climatic conditions during operation
Ambient air temperature
a
a. Temperature of the ambient air at a distance of 5 cm (2 in) from the device
-10 °C ... +60 °C (+14 °F ... +140 °F)
Maximum internal air temperature
b
b. Temperature measured by the temperature sensor within the device.
+75 °C (+167 °F)
Humidity 10 % ... 95 % (non-condensing)
Air pressure min. 700 hPa (+3000 m ASL; +9842 ft ASL)
max. 1060 hPa (-400 m ASL; -1312 ft ASL)
Table 18: Climatic conditions during operation
Climatic conditions during operation
Ambient air temperature
a
a. Temperature of the ambient air at a distance of 5 cm (2 in) from the device
0 °C ... +50 °C (+32 °F ... +122 °F)
Humidity 10 % ... 95 % (non-condensing)
Air pressure min. 700 hPa (+3000 m ASL; +9842 ft ASL)
max. 1060 hPa (-400 m ASL; -1312 ft ASL)
Table 19: Climatic conditions during operation
