Installation GRS103
Release
01
03/2022
M-SFP-BIDI Type
B LH/LC EEC
LH 1590 nm 1490 nm 9/125 µm 5 dB ... 24 dB 23 km ... 80 km
(14.29 mi ... 49.71 mi)
0.25 dB/km 19 ps/(nm×km)
SFP-GIG-BA LX/
LC EEC
SM 1310 nm 1550 nm 9/125 µm 0 dB ... 15 dB 0 km ... 20 km
(0 mi ... 12.43 mi)
0.4 dB/km 3.5 ps/(nm×km)
SFP-GIG-BB LX/
LC EEC
SM 1550 nm 1310 nm 9/125 µm 0 dB ... 15 dB 0 km ... 20 km
(0 mi ... 12.43 mi)
0.25 dB/km 19 ps/(nm×km)
SFP-GIG-BA
LX+/LC EEC
SM 1310 nm 1550 nm 9/125 µm 3 dB ... 20 dB 12 km ... 40 km
(7.45 mi ... 24.86 mi)
0.4 dB/km 3.5 ps/(nm×km)
SFP-GIG-BB
LX+/LC EEC
SM 1550 nm 1310 nm 9/125 µm 3 dB ... 20 dB 12 km ... 40 km
(7.45 mi ... 24.86 mi)
0.25 dB/km 19 ps/(nm×km)
SFP-GIG-BA LH/
LC EEC
LH 1490 nm 1550 nm 9/125 µm 4 dB ... 24 dB 19 km ... 80 km
(11.80 mi ... 49.71 mi)
0.25 dB/km 19 ps/(nm×km)
SFP-GIG-BB LH/
LC EEC
LH 1550 nm 1490 nm 9/125 µm 4 dB ... 24 dB 19 km ... 80 km
(11.80 mi ... 49.71 mi)
0.25 dB/km 19 ps/(nm×km)
a. MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
b. Including 3 dB system reserve when compliance with the fiber data is observed.
Product code Mode
a
Wave length
TX
Wave length
RX
Fiber System
attenuation
Example for F/O line
length
b
Fiber
attenuation
BLP/Dispersion
Table 26: F/O port (bidirectional Gigabit Ethernet SFP transceiver)
