Network Load Control
136
8.2
Multicast Application
Basic Config
uration
Release
6.0
07/2010
Note:
If the device is incorporated in
to a HIPER-Ring, you can use the
following settings to quickly reconf
igure the network for data packets
with registered Multicast destination addresses after the ring is
switched:
X
Activate GMRP on the ring
ports and globally, and
X
activate “Forward all g
roups” on the ring ports.
135
137
