 Interfaces
 Scope of delivery
 Accessories
Note: Please note that products recommended as accessories may have
characteristics that do not fully correspond to those of the corresponding
product. This may limit their possible usage in the overall system.
Basic devices
MACH102-8TP,
MACH102-8TP-R,
MACH102-8TP-F,
MACH102-8TP-FR,
MACH102-24TP-F or
MACH102-24TP-FR
V.24 port: external management
1 terminal block, 2-pin: each 1 x signal contact, max. 1 A, 24 V
USB: ACA 21-USB
MACH102-8TP or MACH102-
8TP-R
- 2 combo ports (alternatively 100/1000 Mbit/s optical SFP
slot or 1000/100/10 Mbit/s RJ45 socket)
- 8 x 10/100 Mbit/s twisted pair, RJ45 socket
- 2 slots for media modules (M1-8TP-RJ45, M1-8MM-
SC, M1-8SM-SC or M1-8SFP)
MACH102-8TP-F or
MACH102-8TP-FR
- 2 combo ports (alternatively 100/1000 Mbit/s optical SFP
slot or 1000/100/10 Mbit/s RJ45 socket)
- 8 x 10/100 Mbit/s twisted pair, RJ45 socket
MACH102-24TP-F or
MACH102-24TP-FR
- 2 combo ports (alternatively 100/1000 Mbit/s optical SFP
slot or 1000/100/10 Mbit/s RJ45 socket)
- 24 x 10/100 Mbit/s twisted pair, RJ45 socket
Media modules
M1-8TP-RJ45 8 x 100 Mbit/s twisted pair, RJ45 socket
M1-8MM-SC 8 x 100 Mbit/s Multimode, duplex SC plug
M1-8SM-SC 8 x 100 Mbit/s Singlemode, duplex SC plug
M1-8SFP 8 x 100 Mbit/s, SFP slot
Device Scope of delivery
MACH102-8TP,
MACH102-8TP-R,
MACH102-8TP-F,
MACH102-8TP-FR,
MACH102-24TP-F or
MACH102-24TP-FR
MACH 100 device
Terminal block for signal contact
Two brackets with fastening screws (pre-mounted)
Housing feet, stick-on
Non-heating appliance cable, Euro model
CD ROM with user manual
Installation user manual
Name Order number
Fast ETHERNET SFP modules:
M-FAST SFP-MM / LC 943 865-001
M-FAST SFP-SM / LC 943 866-001
M-FAST SFP-SM+/ LC 943 867-001
M-FAST SFP-LH / LC 943 868-001
Gigabit ETHERNET SFP modules:
