Entering the IP Parameters
Basic Configuration
Release
6.0
07/2010
2.1
IP Parameter Basics
29
Example of a netmask:
Example of IP addresses with sub
network assignment when the above
subnet mask is applied:
255.255.192.0
Decimal notation
11111111.11111111.11000000.00000000
Binary notation
Subnetwork mask bits
Class B
129.218.65.17
Decimal notation
10000001.11011010.01000001.00010001
binary notation
128 < 129
≤
191
➝
Class B
Subnetwork 1
Network address
129.218.129.17
Decimal notation
10000001.11011010.10000001.00010001
binary notation
128 < 129
≤
191
➝
Class B
Subnetwork 2
Network address
28
30
