56
Installation RSPE30/32/35/37
Release
16
04/2019
Supply voltage
with the
characteristic
value PP
Connection type 2-pin terminal block
Tightening torque
4.5 lb-in
(0.51 Nm)
Rated voltage DC: When using PoE: 48 V DC
When using PoE+: 54 V DC
Without using PoE or PoE+: 24 V DC ...
48 V DC
a
Voltage range DC incl.
maximum tolerances:
When using PoE: 47 V DC ...
57 V DC
Rated power RSPE32 for DC 3.1 A ... 3.5 A
RSPE37 for DC 3.1 A ... 3.5 A
When using PoE+: 53 V DC ...
57 V DC
Without using PoE or PoE+:
19 V DC ...
60 V DC
a
Max. PoE power In total: 124 W
Per media module: 62 W
Power loss buffer >10 ms at 20.4 V DC
Overload current protection on
the device
Non-replaceable fuse
Back-up fuse Nominal rating: 6.3 A
Characteristic: slow blow
Peak inrush current <5 A
