58
Installation RSPE30/32/35/37
Release 16 04/2019
Climatic
conditions
during storage
Ambient air temperature
b
-40 °F ... +185 °F (-40 °C ... +85 °C)
Humidity 5 % ... 95 % (non-condensing)
Air pressure min. 700 hPa (+9842 ft; +3000 m)
max. 1060 hPa (-1312 ft; -400 m)
Signal contact
(exclusively for device variants featuring supply voltage with characteristic value CC and PP)
Connection type 2-pin terminal block
Tightening torque 3 lb-in
(0.34 Nm)
Nominal value I
max
=1A at U
max
=30VAC
I
max
=1A at U
max
=60VDC
according to the UL Standards:
I
max
=1A at U
max
=30VAC
I
max
=1A at U
max
=30VDC
as per ANSI/UL 121201:
See control drawing in chapter “Relevant for use
in explosion hazard areas (Hazardous
Locations, Class I, Division 2):” on page 12
Signal contact
(only for device variants featuring supply voltage with characteristic value K9 and KK)
Connection type 2-pin terminal block
Tightening torque 3 lb-in
(0.34 Nm)
Nominal value I
max
=1A at U
max
= 230 V AC
I
max
=1A at U
max
=60VDC
I
max
= 0.2 A at U
max
= 125 V DC
I
max
= 0.1 A at U
max
= 250 V DC
according to the UL Standards:
I
max
=1A at U
max
=30VAC
I
max
=1A at U
max
=30VDC
as per ANSI/UL 121201:
See control drawing in chapter “Relevant for use
in explosion hazard areas (Hazardous
Locations, Class I, Division 2):” on page 12
Pollution degree 2
Protection
classes
Laser protection Class 1 in compliance with IEC 60825-1
Degree of protection IP20
a. Operation with power supply with characteristic value PP without using PoE or PoE+ in the
range 24 V DC (19 V DC) ... 48 V DC (60 V DC) is not covered by UL approvals.
b. Reduction of the maximum permitted ambient air temperature under specific conditions
c. Temperature of the ambient air at a distance of 2 in (5 cm) from the device
d. Hirschmann recommends to use SFP transceivers with “EEC” extension.
e. Use only SFP transceivers with the “EEC” extension, otherwise the standard temperature
range applies.
f. when equipped with max. 8 SFP transceivers; if a higher number is connected, the following
maximum values apply for the ambient air temperature:
- 9 to 12 transceivers: +149 °F (+65 °C); more than 12 transceivers: +140 °F (+60 °C)
g. when equipped with maximum 8 SFP transceivers; if a higher number is connected, the
following maximum values apply for the ambient air temperature:
9 to 12 transceivers: +176 °F (+80 °C); more than 12 transceivers: +167 F (+75 °C)
