Hisun VECTOR 500 - Specifications

Specifications
5-1
SPECIFICATION TABLE
Engine
Make
Specification
Type
1-cylinder, 4-cycle, gasoline, SOHC, liquid
cooled
Displacement
CC
471cm
Horsepower
Kw(HP)
19.44 HP
Rated revolution
rpm
7000
Low idling revolution
rpm
1350 to 1500
Fuel Capacity
L(U.S.gas)
29（7.6）
Transmission
CVT
Wheels, Drive system
4, Rear 2WD or 4WD
Differential lock
Electric control: switch
Gear selection
L-H-N-R
Brakes
Front/Rear
Wet disk brake
Parking brake
Axis brake, pedal-braking
Steering
Mechanical
Suspension
Front
Independent, Dual A-arm type
Rear
Independent, Dual A-arm type
Dimensions
Length
mm(in.)
2880 (113.83)
Wide
mm (in.)
1550（61.02）
Height
mm (in.)
1885（74.21）
Front tread centers
mm (in.)
1350 (53.15)
Rear tread centers
mm (in.)
1300 (46.5)
Wheelbase
mm (in.)
1841.5（72.5）
Ground
Clearance
front axle
mm (in.)
254（10）
rear axle
254（10）
Turning Radius
m (ft)
3.96（13）
Max. rolling weight (Towing Capacity)
kg (lbs.)
544（1200）
Payload capacity
kg (lbs.)
159（350）
Weight
kg (lbs.)
590（1301）
