Items Specifications
Windows 7 Professional
Windows Server 2008 R2 Standard
Windows Server 2008 R2 Enterprise
Windows Server 2008 Standard 32 bit
Windows Server 2008 Enterprise 32 bit
Windows Server 2003 R2 Standard Edition
1
Windows Server 2003 R2 Enterprise Edition
1
Windows Vista Business
Web browser
Internet Explorer 7 or 8
2
CPU Clock frequency: 2 GHz or higher
Memory
512 MB or larger: 2 GB or greater is recommended.
3
LAN 100Base-TX or greater
CD/DVD drive A CD/DVD drive built in a system console
A CD/DVD drive connected via USB
4
FD drive An FD drive built in a system console
An FD drive connected via USB
Notes:
1. The OS or Web browser of system console need to support a certificate that uses the
SHA2 of hashing algorithms. When using Windows Server 2003 R2, download and
install the hotfix from the following website:
http://support.microsoft.com/kb/938397/en/
2. Need to set the Internet Explorer as follows:
Click Tool > Internet Options > Advanced tab. And then uncheck Do not save
encrypted pages to disk.
When using the Internet Explorer 8:
Click Safety
button > SmartScreen Filter > Turn Off SmartScreen Filter.
3. The remote console use up to 256 MB of memory in each server blade. When using
remote consoles at the same time in multiple server blades, install memory that
have large enough capacity.
4. USB 2.0-based CD/DVD drive is recommended.
5. Connection via TLSv1.1/1.2 is supported by CB 520H B2 server blade with firmware
version 04-22 or later. When connecting via TLSv1.1/1.2, use Oracle Java Version 7
Update 2 or later.
6. When connecting via TLSv1.1/1.2, use Windows 7 or later, or Windows Server 2008
R2 or later.
7. The following 64-bit Oss support 32-bit Java VM as well as 64-bit Java VM.
¢
Windows Server 2012 Standard
¢
Windows 8
¢
Windows 7 Professional
¢
Windows Vista business
1-4
Remote console overview
Hitachi Compute Blade 500 Series Remote Console User's Guide
