105
Troubleshooting
Troubleshooting
If an abnormal operation should occur, stop using the projector immediately.
Otherwise if a problem occurs with the projector, the following checks and measures are
recommended before requesting repair.
If this does not resolve the problem, please contact your dealer or service company. They
will tell you what warranty condition is applied.
Never use the projector if abnormal operations such as smoke,
strange odor, excessive sound, damaged casing or elements or cables, penetration
of liquids or foreign matter, etc. should occur. In such cases, immediately disconnect
the power plug from the power outlet. After making sure that the smoke or odor has
stopped, contact to your dealer or service company.
WARNING
Related messages
When some message appears, check and cope with it according to the following table.
Although these messages will be automatically disappeared around several minutes, it will
be reappeared every time the power is turned on.
Message Description
There is no input signal.
Please conrm the signal input connection, and the status
of the signal source.
Projector is waiting for an image le.
Check the hardware connection, settings on the projector
and network-related settings.
The computer-Projector network connection might be
disconnected. Please re-connect using “Connect button” of
the “LiveViewer”.
Troubleshooting
(continued on next page)

Other manuals for Hitachi CP-AX3505

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Hitachi CP-AX3505 and is the answer not in the manual?

Hitachi CP-AX3505 Specifications

General IconGeneral
PlacementCeiling
Product typeUltra short throw projector
Product colorWhite
Number of colors16.78 million colors
Projection technology-
Contrast ratio (typical)10000:1
Screen size compatibility60 - 100 \
Projector native resolutionXGA (1024x768)
Projector brightness (economic mode)2214 ANSI lumens
FocusAuto
Digital zoom1.35 x
Focal length range- mm
Lamp power250 W
Light source typeLamp
Service life of light source4000 h
Service life of light source (economic mode)5000 h
Full HDNo
Supported video modes480i, 480p, 576i, 720p, 1080i, 1080p
Analog signal format systemNTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
PC in (D-Sub)Yes
Serial interface typeRS-232C
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level36 dB
CertificationUL/CUL, FCC PART15 CLASS B, AS/NZS CISPR22 CLASS B, CE, ROHS, GOST-R
Noise level (economic mode)29 dB
Operating temperature (T-T)0 - 40 °C
Power sourceAC
AC input voltage220 - 240 V
Power consumption (standby)0.35 W
Power consumption (typical)350 W
Sustainability certificatesRoHS
RMS rated power16 W
Weight and Dimensions IconWeight and Dimensions
Depth360 mm
Width377 mm
Height136 mm
Weight4300 g
