Hitachi CP-AX3505 User Manual

92
Presentation tools
Display : The Floating menu is displayed, and the icon disappears from the
Windows notication area.
Quit : The application is closed, and the icon disappears from the Windows
notication area.
The menu shown in the right will be displayed
when you right-click the application icon in the
Windows notication area.
USB Display(Windows computer) (continued)
Right-Click menu
• If you wish to restart the application, you need to unplug the USB
cable and plug it again.
NOTE
If you select “Display” on the Right-Click
menu, the Floating menu shown in the right
will appear on your computer screen.
 Start capture button
The transmission to the projector is started
and the images will be displayed.
 Stop button
The image transmission is stopped.
 Hold button
The image on the projector’s screen is temporally frozen. The last image before
the button is clicked is remained on the screen. You can revise the image data
on your computer without showing it on the projector's screen.
 Option button
The Options window is displayed.
 Minimize button
The Floating menu is closed, and the icon reappears in the Windows notication
area.
Floating menu
• If you click the Start capture button and/or Stop button repeatedly,
images may not be displayed on the screen.
NOTE


  

Hitachi CP-AX3505 Specifications

General

Placement	Ceiling
Product type	Ultra short throw projector
Product color	White
Number of colors	16.78 million colors
Projection technology	-
Contrast ratio (typical)	10000:1
Screen size compatibility	60 - 100 \
Projector native resolution	XGA (1024x768)
Projector brightness (economic mode)	2214 ANSI lumens
Focus	Auto
Digital zoom	1.35 x
Focal length range	- mm
Lamp power	250 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
Full HD	No
Supported video modes	480i, 480p, 576i, 720p, 1080i, 1080p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
PC in (D-Sub)	Yes
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	36 dB
Certification	UL/CUL, FCC PART15 CLASS B, AS/NZS CISPR22 CLASS B, CE, ROHS, GOST-R
Noise level (economic mode)	29 dB
Operating temperature (T-T)	0 - 40 °C
Power source	AC
AC input voltage	220 - 240 V
Power consumption (standby)	0.35 W
Power consumption (typical)	350 W
Sustainability certificates	RoHS
RMS rated power	16 W

Weight and Dimensions

Depth	360 mm
Width	377 mm
Height	136 mm
Weight	4300 g
