Hitachi CP-WU8450 User Manual

34
Operating
Correcting the distortion (continued)
4.
This projector is equipped with a memory feature for PERFECT FIT
adjustment. Up to 3 sets of adjustments can be stored.
● SAVE:
To store the current PERFECT FIT adjustment, select one of the SAVE
icons
numbered 1 to 3 (number of the memory) with the ◄ /▲/▼ buttons
and press the ENTER or INPUT button.
Remember that the current data being stored of a memory will be lost by
saving new data into the memory.
● LOAD:
To recall stored adjustments, select one of the LOAD icons
numbered
1 to 3 (number of the memory) with the ◄ /▲/▼ buttons and press the
ENTER or INPUT button.
Remember that the current adjusted condition will be lost by loading data. if
you want to keep the current adjustment, please save it before performing
a LOAD function.
• <Only for CP-X8150, CP-X8160, CP-WX8240 and CP-WX8255>
Each corner and side can be adjusted individually but in some cases it may
be adjusted in conjunction with another corner or side. This is due to control
restrictions and not a malfunction.
• The LOAD functions whose linked memory has no data are skipped.
• There may be some noise and the screen may icker for a moment when
loading data. This is not malfunction.
• Point at RETURN in the dialog with the ▲/▼ buttons and press the ◄ or
ENTER button to return to the KEYSTONE menu.
NOTE
3.
Adjust the selected part as below.
● For adjusting a corner, use the ▲/▼/◄/► buttons to adjust the position of
the corner.
● <Only for CP-X8150, CP-X8160, CP-WX8240 and CP-WX8255>
For adjusting the upper or lower side, use the ◄/► buttons to select any
one point on the side, and use the ▲/▼ buttons to adjust the distortion of
the side.
● <Only for CP-X8150, CP-X8160, CP-WX8240 and CP-WX8255>
For adjusting the left or right side, use the ▲/▼ buttons to select any one
point on the side, and use the ◄/► buttons to adjust the distortion of the
side.
● To adjust another corner or side, press the ENTER or INPUT button and
follow the procedure from step 2.

Hitachi CP-WU8450 Specifications

General

Matrix size	0.76 \
Matrix type	3-panel (p-Si TFT active)
Native aspect ratio	16:10
Projection distance	1 - 38.3 m
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	30 - 600 \
Projector native resolution	WUXGA (1920x1200)
Audio input	3
RS-232 ports	1
Zoom capability	Yes
Focal length range	- mm
Lamp type	UHP
Lamp power	330 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	- h
3D	-
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
RMS rated power	16 W
Number of built-in speakers	2
DVI port	No
BNC input ports	5
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Noise level	- dB
Certification	UL/cUL, FCC Part15 class A, AS/NZS CISPR22 class A, CE, GOST-R
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Power source	AC
AC input voltage	100 - 240 V
Power consumption (standby)	- W
Operating temperature (T-T)	0 - 45 °C
Sustainability certificates	RoHS

Weight and Dimensions

Depth	396 mm
Width	498 mm
Height	135 mm
Weight	8700 g
