105
14. STANDARD SPECIFICATIONS
DSP-132WN, 145WN, 160WN
Model DSP-132W6N DSP-145W6N DSP-160W6N
Air Compressor
Working Pressure
MPa (psi)
0.75/0.86/1.0 (110/125/145)
Ambient Operating Pressure and
Temperature
℃(℉)
Atmospheric Pressure, 0 to 40 (32 to 104)
Gases Handled
Air
Capacity
m
3
/min (cmf)
23.4/21.8/19.6 (826/770/692) 26.0/23.7/20.6 (918/837/727)
28.5/26.2/23.2 (1006/925/819)
No. of Compression Stage
Two Stage
Driving Method
Driving by Stepup Gear
Motor Starting Method
Star-Delta Starting
Discharge Air Pipe Connection
inch 2-
½
(flange connection)
Discharge Air Temperature
℃(℉)
Cooling Water Temperature 13 (23.4), or less
Cooling Water Pipe Connection
inch 2
Cooling Water Temperature
℃(℉)
32 (90) or less
Cooling Water Quantity
L/min (cmf)
200 (7.1) 210 (7.4) 240 (8.5)
Oil System Capacity
L (US gallon)
40 (10.6) (Not filled)
Capacity Control System
Offl ine or online, 0
or 100
, 2-step control by suction throttle valve
Main Motor
Nominal Output kW (HP) 132 (177) (SF 1.15) 145 (194) (SF 1.1) 170 (228) (SF 1.035)
Type
TFO-KK Totally Enclosed Motor
Voltage V 460 460 460
Maximum current A 240 250 275
Frequency Hz 60 60 60
Number of Pole
4-Pole
Insulation Class
Class F
Cooling Fan Motor
Nominal Output kW (HP) 0.4 (0.54)
Type
PN-404-04H
Voltage V 460 460 460
Current A 1.0 1.0 1.0
Frequency Hz 60 60 60
Number of Pole
4-Pole
Insulation Class
Class E
Other
Oil Cooler
Water-Cooled Horizontal Shell-and-Tube Type (Water: inside, Oil: outside)
Intercooler
Water-Cooled Horizontal Shell-and-Tube Type (Water: outside, Air: inside)
Aftercooler
Water-Cooled Horizontal Shell-and-Tube Type (Water: outside, Air: inside)
Total Weight kg (lb) 3,800 (8,378)
External Dimensions (W×D×H)
mm (inch)
2,500×1,600×1,925 (98.4×63.0×75.8)
NOTE:
(1) Performance of the compressor package measured in accordance with ISO1217, Third Edition, Annex C.
(2) The appearance and specifications are subject to change without notice.
(3) Use the current value as reference data only. The amperage current may vary from phase to phase.
