Hitachi DSP-160V6WN User Manual

107
14. STANDARD SPECIFICATIONS
■ DSP-160VWN, 240WN
Model DSP-160VW6N DSP-240VW6N
Air Compressor
Working Pressure MPa (psi) 0.75/0.86/1.0 (110/125/145)
Ambient Operating Pressure and
Temperature
℃(℉)
Atmospheric Pressure, 0 to 40 (32 to 104)
Gases Handled
−
Air
Capacity
m
3
/min (cmf) 28.5/26.2/23.2 (1006/925/819) 40.5/36.9/32.5 (1430/1303/1148)
No. of Compression Stage
−
Two Stage
Driving Method
−
Driving by Stepup Gear
Motor Starting Method
−
Inverter
Discharge Air Pipe Connection inch 2-1/2 (flange connection) 3 (flange connection)
Discharge Air Temperature
℃(℉)
Cooling Water Temperature 13 (23.4), or less
Cooling Water Pipe Connection inch 2
Cooling Water Temperature
℃(℉)
32 (90) or less
Cooling Water Quantity
L/min (cmf) 240 (8.5) 330 (11.7)
Oil System Capacity L (US gallon) 40 (10.6) (Not filled) 50 (13.2) (Not filled)
Capacity Control System
−
Variable Speed + Purge + Motor Auto start / stop control
Main Motor
Nominal Output kW (HP) 170 (228) (SF 1.035) 240 (322) (SF 1.1)
Type
−
TFO-KK Totally Enclosed Motor
Voltage V 460
Maximum current A 275 399
Frequency Hz 60
Number of Pole
−
4-Pole
Insulation Class
−
Class F
Cooling Fan Motor
Nominal Output kW (HP) 0.4 (0.54)
Type
−
PN-404-04H
Voltage V 460
Current A 1.0
Frequency Hz 60
Number of Pole
−
4-Pole
Insulation Class
−
Class E
Other
Oil Cooler
−
Water-Cooled Horizontal Shell-and-Tube Type (Water: inside, Oil: outside)
Intercooler
−
Water-Cooled Horizontal Shell-and-Tube Type (Water: outside, Air: inside)
Aftercooler
−
Water-Cooled Horizontal Shell-and-Tube Type (Water: outside, Air: inside)
Total Weight kg (lb) 4,000 (8,819) 5,100 (11,244)
External Dimensions (W×D×H) mm (inch) 2,500×1,600×1,925 (98.4×63.0×75.8) 2,800×1,800×1,950 (110.2×70.9×76.8)
NOTE:
(1) Performance of the compressor package measured in accordance with ISO1217, Third Edition, Annex C.
(2) The appearance and specifications are subject to change without notice.
(3) Use the current value as reference data only. The amperage current may vary from phase to phase.
