■ Messages of Automatic Stop Display and Automatic Restart Display
When the DSP air compressor has automatically stopped, the following screen is displayed, the AUTO START light
flashes/lights, and the RESTART message screen and details of contents flash on the LCD monitor.
㻞㻜㻜㻥䠋㻜㻤䠋㻜㻝 㻝㻥䠖㻜㻞 㻖
㼀㼅㻼㻱 䠖 㼂㻿㻰㻭㻌
㻌㻌 㻌㻌㻌
㻰 㻵 㻿 䠊 㻼 㻾 㻱 㻿 㻿 䠖 䚷䚷 㻢 㻣 㼜 㼟 㼕
䠘㻾㻱㻿㼀㻭㻾㼀䠚
㻾 㻱 㻿 㼀 㻭 㻾 㼀 㻭 㼀 䠖 䠆䠆 䠖 䠆䠆
㻾㻱㻿㼀㻭㻾㼀 㼃㻭 㻵 㼀䠖 㻌 㻞 㻣䡏
㻺㻻㼃䠈㻿 㼀㻻㻼㻼 㻱 㻰 䠞䠵 䠖
㻿㻯㻴㻱㻰㼁㻸㻱 㻿㼀㻻㻼
㻭㼁㼀㻻㻹㻭㼀 㻵 㻯 㻿㼀㻻㻼
㻰㻾㼅㻱㻾 㻼㻾㻱㻿㼀㻭㻾㼀㻱㻰
㻰㼁㻭㻸䠋㻮㻭㻯㻷㼁㻼
㻵 㻼 㻵 㻌 㻾㻱㻿㼀㻭㻾㼀
㻯㼀㻸㻾䠊㻾㻱㼀㻾㼅
16
3. OPERATING THE DSP [How to Use the Liquid Crystal Display (LCD)]
● SCHEDULED STOP: Schedule operation setting
＜AUTO light ON＞
When schedule is set on the scheduled operation
screen, displays state of operation being stopped by
preset time. Operation starts automatically when the
preset restart time comes.
● LEAD/LAG OPERATION STOP
(Note: applies only to machines equipped with two-
unit alternate operation.)
＜AUTO light ON＞
When the operation control mode is set to dual or
backup on the operation mode setting screen, standby
status of the slave machine in dual or backup operation
is indicated.
● DRYER PRESTARTED
(Note: Applies only to machines equipped with a
built-in dryer.)
＜AUTO START light flashes＞
When dryer prestart is set, the dryer starts operating
in advance, and compressor stopped status is indicat-
ed.
RESTART WAIT time is counted down.
● AUTO OPERATION
(Note: Applies only to machines equipped with
AUTO function)
＜AUTO START light ON＞
Indicates status stopped by low load when set to
AUTO operation. AUTO START light flashes during
restart limit while stopped, and RESTART WAIT time
is counted down.
● INSTANT STOP / RETRY
(Note: Retry applies to V type only.)
＜AUTO START light flashes＞
Displays status of restart for instantaneous power
interruption (IPI) restart and V type retry.
RESTART WAIT time is counted down.
To Next Page
