Hitachi HDS723020BLA642 - Table 159 Error Data Structure

To Next Page

To Previous Page

Hitachi hard disk drive specifications

227

Error data structure: Data format of error data structure is shown below.

Description

Bytes

Offset

Reserved

00h

Error register

01h

Sector count register

02h

Sector number register

03h

Cylinder Low register

04h

Cylinder High register

05h

Device/Head register

06h

Status register

07h

Extended error data (vendor specific)

08h

State

1Bh

Life timestamp (hours)

1Ch

Table 159 Error data structure

State field contains a value indicating the device state when command was issued to the device.

Value

State

x0h

Unknown

x1h

Sleep

x2h

Standby

x3h

Active/Idle

x4h

SMART Off-line or Self-test

x5h-xAh

Reserved

xBh-xFh

Vendor specific

Note: The value of x is vendor specific.
