Hitachi HDS723020BLA642 - Table 160 Self-Test Log Data Structure

Hitachi hard disk drive specifications
228
11.43.6 Self-test log data structure
The following defines the 512 bytes that make up the Self-test log sector. All multi-byte fields shown in these
data structures follow the ATA/ATAPI-7 specifications for byte ordering.
Description
Bytes
Offset
Data structure revision
2
00h
Self-test number
1
n*18h+02h
Self-test execution status
1
n*18h+03h
Life time power on hours
2
n*18h+04h
Self-test failure check point
1
n*18h+06h
LBA of first failure
4
n*18h+07h
Vendor specific
15
n*18h+0Bh
…
Vendor specific
2
1Fah
Self-test index
1
1FCh
Reserved
2
1FDh
Data structure checksum
1
1FFh
512
Note: n is 0 through 20
Table 160 Self-test log data structure
The data structure contains the descriptor of Self-test that the device has performed. Each descriptor is 24 bytes
long and the self-test data structure is capable to contain up to 21 descriptors.
After 21 descriptors have been recorded, the oldest descriptor will be overwritten with new descriptor.
Self-test index points the most recent descriptor. When there is no descriptor the value is 0. When there is
descriptor(s) the value is 1 through 21.
