Basic operation
To save adjustment settings
Note that if the MESSAGE function (51) is inactive, the following procedure
cannot be performed and the projector will load saved adjustment settings as
soon as the MEMORY button is pressed.
When the MESSAGE function is inactive please use the MY MEMORY function in
the PICTURE menu (42) to save adjustment settings.
When the MESSAGE function is active, the MY MEMORY menu can be displayed
using the following procedure. The MY MEMORY menu displayed is the same as
in the PICTURE menu. You cannot only save adjustment settings but also change
and rename previously saved adjustment settings via this menu.
1.
When the current adjustment settings are from one of the saved memories a
dialog shows which memory is being used.
When the current settings are not saved to memory the following dialog is
displayed.
2.
Press the ENTER button while the dialog is displayed to
open the MY MEMORY menu and save to the currently
selected memory.
• The numbers to the left of each memory cannot be changed but the
name to the right can be changed.
• The MY MEMORY function can also be accessed via the PICTURE menu in
the Advanced Menu (
42).
NOTE
Press the MEMORY button once.
The projector will display a dialog to indicate the current adjustment settings.
3.
Please refer to the MY MEMORY item under PICTURE
menu (42) for more information on using the MY
MEMORY menu.
Te mporary condition
E NTER ; Save these parameters
M EMORY ; Recall saved parameters
; Quit
ENTER
MEMORY
MY MEMORY
SHARPNESS +3
BRIGHTNESS ＋
0
CONTRAST ＋0
COLOR +0
TINT +0
COLOR TEMP 6500K
GAMMA STANDARD
IRIS 10
BLACK TURN OF
F
DIGITAL SHUTTER
TURN OFF
WHISPER NORMAL
:SELECT
NAME CUSTOM‑1
:QUIT
MENU
SAVE
