Hitachi S1 Series User Manual

S1 series standard inverter
-96-
Function
code
Name
Detailed parameter description
Default
value
Modify
required;
2: Static autotuning 1 (comprehensive
autotuning); static autotuning 1 is used in cases
where the motor cannot be disconnected from
load;
3: Static autotuning 2 (partial autotuning) ; when
current motor is motor 1, only P02.06, P02.07 and
P02.08 will be autotuned; when current motor is
motor 2, only P12.06, P12.07 and P12.08 will be
autotuned.
P00.16
AVR function
0: Invalid
1: Valid during the whole process
Automatic voltage regulation function is used to
eliminate the impact on the output voltage of
inverter when bus voltage fluctuates.
1
○
P00.17
Inverter type
0: ND;
1: LD;
0
P00.18
Function
parameter
restoration
0: No operation
1: Restore to default value
2: Clear fault history
Note: After the selected function operations are
done, this function code will be restored to 0
automatically. Restoration to default value will
clear the user password, this function should be
used with caution.
0
◎
P01 group Start/stop control
P01.00
Running mode of
start
0: Direct start
1: Start after DC brake
2: Start after speed-tracking 1
3: Start after speed-tracking 2
Note: This function is only available for the
inverters≥4kW
0
◎
P01.01
Starting
frequency of
direct start
Starting frequency of direct startup is the initial
frequency when the inverter starts. See P01.02
(hold time of starting frequency) for details.
Setting range: 0.00–50.00Hz
0.50Hz
◎

Hitachi S1 Series Specifications

General

Output Frequency	0 - 400 Hz
Overload Capacity	150% for 60 seconds
Frequency	50/60 Hz
Control Method	Sensorless Vector Control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication	RS485, Modbus RTU
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC (Matches Input Voltage)
Cooling Method	Fan Cooled
