97 Intelligent input terminal 1 active state C20 IN-TM O/C-1 NO C011 00(NO)
Logic conversion for the intelligent input terminal 5 to 8 of the
SJ300 can be also possible by C015 to C018.
98 Intelligent input terminal 2 active state IN-TM O/C-2 NO C012 00(NO)
99 Intelligent input terminal 3 active state IN-TM O/C-3 NO C013 00(NO)
100 Intelligent input terminal 4 active state
IN-TM O/C-4 NO C014 00(NO)
101 Intelligent output terminal 11 function C10 F-35 OUT-TM 1 FA1 C021 01(FA1)
102 Intelligent output terminal 12 function C11 OUT-TM 2 RUN C022 00(RUN)
103 Alarm relay terminal active state OUT-TM O/C-A NC C036 01(NC)
104 Intelligent input terminal 11 active state OUT-TM O/C-1 NO C031 00(NO)
105 Intelligent input terminal 12 active state
C21
OUT-TM O/C-2 NO C032 00(NO)
106 Monitor signal selection A44 F-37 MONITOR A-F C027 00
107 Operation mode on expansion card 1 error - F-47 OP-ERR1 STP P001 00
108 Operation mode on expansion card 1 error - OP-ERR2 STP P002 00
109 Encoder pulse-per-revolution setting - F-39 OP P 1024 pulses P011 1024
110 Control pulse setting - OP MODE ASR P012 00
111 R0-T0 PCB selection A99 OP R0-T0 OFF - -
R0-T0 function is provided as standard in the case of the
SJ300.
112 Home search stop position selection - F-40 OR POS IN - -
113 Home search stop position setting - OR P 0 pulse P014 0.
114 Home search speed setting - OR FC 5.0Hz P015 5.00
115 Home search direction setting - OR TURN FWD P016 00
116 Home search completion range setting - OR L 5pulse P017 5
117 Home search completion delay time setting - OW TW 0.00s P018 0.00
118 Electronic gear set position selection - F-41 PO EGRP FB P019 00
119 Electronic gear ratio numerator setting - PO EGR-N 1 P020 1
120 Electronic gear ratio denominator setting - PO EGR-D 1 P021 1
121 Feed-forward gain setting - PO FFWG 0.00 P022 0.00
122 Position loop gain setting - PO D 0.5rad/s P023 0.50
123 Torque limit selection - F-42 TRQ LIMIT REM b040 00
124 Torque limit (forward) setting - TRQ FWD 150% b041/b042 150
Forward-driving/reverse-regenerating can be set
independently in the case of the SJ300.
125 Torque limit (reverse) setting - TRQ REV 150% b043/b044 150
Reverse-driving/forward-regenerating can be set
independently in the case of the SJ300.
126 PID setpoint input selection A95 F-43 PID IN-SEL IN - -
The current frequency command serves as the setpoint.
(SJ300)
127 PID setpoint setting A96 PID LVL 0.0% F001 0.00
The current frequency command serves as the setpoint.
(SJ300)
128 PID proportional gain A90 PID P 1.0 A072 1.0
129 PID integral time constant A91 PID I 1.00s A073 1.0
130 PID derivative time constant A92 PID D 0.0 A074 0.00
131 PID enable A94 PID MODE 0 A071/A076 00/00 (OI)
132 Communication speed selection - F-46 COM BAU 600bps C071 04 (4800bps)
133 Node allocation - COM NUMBER 01 C072 1
134 Communication data length selection - COM LENGTH 8 C073 7
135 Communication parity selection - COM PAR-SEL1 ON
136 Even parity/odd parity selection - COM PAL-SEL2 EVN
C074 00
137 Communication stop bit selection - COM STOPBIT 2 C075 1
J300 SJ300No. Name
Function code Default Function Default setting
Remarks
