Table 1 16-Gbps, 32-Gbps Fibre Channel
Number Item Description
1 Fibre Channel connectors Connect to Fibre Channel
cables.
2 STATUS LED Green: Front end module is
in the power-on state.
Red: Front end module has
an error.
3 PORT LED Red: Small form-factor
pluggable can be removed.
Blue: Normal link status at
16-Gbps (16-Gbps).
Blue: Normal link status at
32-Gbps (32-Gbps).
Green: Normal link status
at 4-Gbps or 8-Gbps (16-
Gbps).
Green: Normal link status
at 8-Gbps or 16-Gbps (32-
Gbps).
Port assignments for 16-Gbps or 32-Gbps Fibre Channel board
Number Port 1 Port 2 Port 3 Port 4
CHB-01A 1A 3A 5A 7A
CHB-01B 1C 3C 5C 7C
CHB-01E 1E 3E 5E 7E
CHB-01F 1G 3G 5G 7G
CHB-02A 1B 3B 5B 7B
CHB-02B 1D 3D 5D 7D
CHB-02E 1F 3F 5F 7F
CHB-02F 1H 3H 5H 7H
CHB-11A 2A 4A 6A 8A
CHB-11B 2C 4C 6C 8C
Port assignments for 16-Gbps or 32-Gbps Fibre Channel board
Chapter 2: Hardware overview
Hitachi Virtual Storage Platform 5000 Series Hardware Guide 23
