Number Item Description
Blinking (Red): A failure has
occurred. The port is
blocked.
On (Red): The cable can be
removed.
O: Link down state.
4 STATUS On (Green): The module is
powered on.
On (Red): The module can
be removed.
O: The module is powered
o.
Port assignments for fabric-acceleration module
Fabric-Acceleration
Module Number Port 0 Port 1
HIE-01C HIE-01C-0 HIE-01C-1
HIE-01G HIE-01G-0 HIE-01G-1
HIE-02C HIE-02C-0 HIE-02C-1
HIE-02G HIE-02G-0 HIE-02G-1
HIE-11C HIE-11C-0 HIE-11C-1
HIE-11G HIE-11G-0 HIE-11G-1
HIE-12C HIE-12C-0 HIE-12C-1
HIE-12G HIE-12G-0 HIE-12G-1
Drive box
Drive boxes are compact storage enclosures that hold large numbers of drives and can
be installed in a small rack space (EIA-standard rack units).
Port assignments for fabric-acceleration module
Chapter 2: Hardware overview
Hitachi Virtual Storage Platform 5000 Series Hardware Guide 26
