Specifications
A–5
Hitachi VSP User and Reference Guide
Table A-5 PDU plugs, circuit breakers, and receptacles
1
Figure A-1 Rack numbers
Phase Location PDU Plug
Max
Voltage
Rating
Max
Current
Rating
No. of CB
per PDU
Breaker
Rating
Power Supply
Receptacle IEC
C14
2
Single Americas
(except
Brazil)
NEMA L6 30P
twistlock
2 pole, 3 wire
A + B + gnd
208 V 30 A
per PDU
2 16 A,
20 A trip
2 pole, 3 wire
220 VAC
A + B + gnd
EMEA /
APAC/
Brazil
IEC 309, blue
2 pole, 3 wire
A + B + gnd
230 V 32 A
per PDU
2 16 A,
20 A trip
2 pole, 3 wire
220 VAC
A + B + gnd
Three Americas
including
Brazil
NEMA L15 30P
twistlock
3 pole, 4 wire
A + B + C + gnd
208 V 30 A per
phase
3 UL489 15 A
2 pole
2 pole, 3 wire
220 VAC
A-B or B-C + gnd
APAC/
EMEA
IEC 309, red
4 pole, 5 wire
A + B + C + Neut
+ gnd
400 V 32 A per
phase
6 16 A
2 pole
1 pole, 3 wire
200 VAC
A-N or B-N or
C-N + gnd
Required number of plugs in each
PDU
per chassis
Controller chassis Drive chassis Same power cord
and plug for all
power supplies.
44
Required number of PDUs per rack Controller rack Drive rack Same power cord
and plug for all
PDPs.
2 if only controller
installed
4 if controller and
drive chassis
4
NOTES:
1. The numbers in this table were taken from the PDU manufacturer’s specifications. See the
manufacturers specifications at the end of this appendix.
2. This information shows how the receptacles is wired inside the PDU. The equivalent IEC plug for this
receptacle is IEC 13.
