Hitachi VSP User and Reference Guide
A–2
Specifications
Mechanical specifications
The following table lists the mechanical specifications of the VSP storage
system.
Table A-1 VSP mechanical specifications
Electrical specifications
The VSP storage system can use single phase or three phase AC power for
both open and mainframe systems.
• Table A-2 VSP electrical specifications. single phase current on page A-
3 lists the single phase specifications.
• Table A-3 VSP Electrical specifications. three phase current on page A-4
lists the three phase power requirements.
• Table A-5 PDU plugs, circuit breakers, and receptacles1 on page A-5 lists
the PDU specifications for both single phase and three phase power.
Note: The weight and electrical specifications in the following tables were
taken from a VSP storage system in a controlled environment. To calculate
the weight and current draw of a specific system, use the Power and Weight
calculator at
http://www.hds.com/go/weight-and-power-calculator/
Contact technical support if you need assistance using this tool.
Dimension Single Rack
Single Module
(3 racks)
Dual Module
(6 racks)
Width (inches / mm) 24.0 / 610 71.3 / 1810 142.1 / 3610
Depth (inches / mm) 43.3 / 1100 43.3 / 1100 43.3 / 1100
Height (inches / mm) 73.1 / 2005 73.1 / 2005 73.1 / 2005
System
Weight
Min (lbs / kg) 767 / 346 (Diskless) 3610 / 1628 7503 / 3384
Max (lbs / kg) 862 / 389 4592 / 2071 9784 / 4413
Rack
Weight
(lbs / kg) 292.6 / 133 Rack Weight is included in system
weight
