System Components
3–3
Hitachi VSP User and Reference Guide
The following illustrations show the front and rear views of a controller
chassis that is configured with the minimum number of components. The
system control panel (#1 in the front view) is described in the next section.
Figure 3-1 Controller chassis - front view (minimum configuration)
Item Description Item Description
Control Panel Fan (10 total)
Cache (optional) Cache Memory Adapter
Space for additional Virtual
Storage Director
Virtual Storage Director
(microprocessor board)
