Hitachi ZAXIS 135US-6 class User Manual

SPECIFICATIONS
12-3
Shoe Types and Applications
ZX135US-6
Shoe Width
500 mm
Grouser Shoe
600 mm
Grouser Shoe
700 mm
Grouser Shoe
Application
For Ordinary
Ground
(Standard)
For Weak Footing
(Option)
For Weak Footing
(Option)
Operating Weight kg 13800 14100 14300
Base Machine Weight kg 11100 11400 11700
Counterweight Weight kg 3520 3520 3520
Cab Height mm 2790 2790 2790
Minimum Ground
Clearance
mm *410 *410 *410
Undercarriage Length mm 3580 3580 3580
Undercarriage Width mm 2490 2590 2690
Ground Pressure
43 kPa
(0.44 kgf/cm
2
)
37 kPa
(0.38 kgf/cm
2
)
32 kPa
(0.33 kgf/cm
2
)
f
NOTE:
The Specifications for the front-end attachment is for 2.52 m arm with PCSA 0.50 m3 bucket.
Other than 500 mm grouser shoe should not be used on gravel or rocky ground.
* The dimensions do not include the height of the shoe lug.
