PMAC 3000 Page30
Specifications
SensorInterface
InputRange.................................................................................................................. +/‐4.5mV/V
Polarity................................................................................................................................. Bipolar
BridgeExcitation..................................................................................................................... 5VDC
MinimumBridgeImpedance................................................................................................. 120
MaximumBridgeImpedance............................................2000(seeSensorConnection,p.20)
SampleRate‐PeakModes.......................................................................10,000samples/second
SampleRate‐RecordModes.......................... UserSelectablefrom1to10,000samples/second
FrequencyResponse–PeakModes............................................................................‐ 3dBat1kHz
FrequencyResponse–RecordModes......upto1kHz,samplesaveragedforslowersamplerates
SampleRate‐TrackMode...........10,000samples/secondaveragedtomake4readings/second
Accuracy......................................................................................................+/‐.02%ofInputRange
EncoderInterface(optional)
InputType................................................................................................... QuadratureTTL/CMOS
PowerSupply................................................................................................... 5VDC,100mAmax.
MaximumPulseRate........................................................................................................... 200kHz
AngleSampleRate....................................................................................10,000samples/second
RPMSampleRate...............10,000samples/second,differencecalculatedoverlast.05seconds
AnalogOutput
Range........................................................................... UserSelectable+/‐10V,+/‐5V,0‐10V,0‐5V
Resolution....................... 14to16bitsover+/‐FSCapacityofSensor(seeAnalogOutput,p.16)
FrequencyResponse................................................................................................... ‐ 3dBat1kHz
UpdateRate..............................................................................................10,000samples/second
DataOutput.......................................................................... USB2.0(InterfaceSoftwareIncluded)
Power
ACAdapter.....................................................................................UniversalInput,12VDCOutput
Batteries..................................................................................................RechargeableLi‐IonPack
Physical
Height...................................................................................................................................... 4.55”
Width....................................................................................................................................... 6.05”
Depth....................................................................................................................................... 2.78”
Weight................................................................................................................................... 2.0lbs
Environment
OperatingTemperatureRange(batterycharging)................................... 0to45°C /32to113°F
OperatingTemperatureRange(batterynotcharging)........................... ‐ 20to60°C/‐4to140°F
StorageTemperatureRange....................................................................... 0to35°C/32to95°F
