HITEC X1 Pro - Lithium Battery Meter

41
The X1 Pro allows you to check a battery’s total voltage, the high-
est voltage, the lowest voltage and each cell’s voltage.
Connect the battery in the same manner as you would for charg-
ing.
When you power on the X1 Pro you will be
at the “
PROGRAM SELECT” screen. Toggle
up (▲) until you see “
LI BATT METER”.
Toggle right (►) once and the screen will
displaly the voltage of each cell.
Toggle up (▲) or down (▼) once and the
screen will display the total voltage, highest
voltage and the lowest voltage.
Once the prole has been saved, the “
BATT MEMORY” screen will
appear. The second line on this screen will automatically scroll
through the various parameters that have been set for this battery
prole.
To load a preset battery prole enter the “
BATT MEMORY” screen
and toggle up (▲) or down (▼) to nd the prole number you
wish to use. Toggle and hold the joysick to the right (►) for three
seconds and the prole will be loaded.
PROGRAM SELECT
LI BATT METER
4.09 4.09V 4.09V
0.00 0.00V 0.00V
MAIN 12.52V
H4.190V L4.160V
BATTERY MEMORY cont.
LITHIUM BATTERY METER
